GL2035

GL2035

The **Digging Grab GL2035 by DMS Technology** with horizontal hydraulic cylinder is our attachment solution for efficient digging of trenches and shafts. Due to the optimized shell shape, the **movement of bulk material and the gripping of larger objects** is possible at the same time. The grab’s patented cylinder design combines a compact structure with strong, double-acting closing force and high damage resistance. The **Digging Grab GL2035** is available as a fixed mount or swinging mount version.

Low profile design
Low profile
The grab is characterized by its low overall height in both open and closed positions. Its compact design supports an optimized balance between weight and performance.
Optimal grip design
Optimal grip
With their wide opening span and large capacity, the shells enable efficient digging operations as well as the handling of various types of materials.

Due to high-quality material composition and optimal lubrication.

Vulnerable components are completely enclosed and protected.

Innovations such as Softgrip and Pipegrip open up new application possibilities.

GL2035

The **Digging Grab GL2035 by DMS Technology** with horizontal hydraulic cylinder is our attachment solution for efficient digging of trenches and shafts. Due to the optimized shell shape, the **movement of bulk material and the gripping of larger objects** is possible at the same time. The grab’s patented cylinder design combines a compact structure with strong, double-acting closing force and high damage resistance.

Description

The **Digging Grab GL2035 by DMS Technology** with horizontal hydraulic cylinder is our attachment solution for efficient digging of trenches and shafts. Due to the optimized shell shape, the **movement of bulk material and the gripping of larger objects** is possible at the same time. The grab’s patented cylinder design combines a compact structure with strong, double-acting closing force and high damage resistance. The **Digging Grab GL2035** is available as a fixed mount or swinging mount version.

Low profile design
Low profile
The grab is characterized by its low overall height in both open and closed positions. Its compact design supports an optimized balance between weight and performance.
Optimal grip design
Optimal grip
With their wide opening span and large capacity, the shells enable efficient digging operations as well as the handling of various types of materials.
Capacity [l] 50
Weight (without rotator) [kg] 115
Weight rotator [kg] 20
Operating pressure opening/closing [bar] 250
Operating pressure rotation [bar] 250
Recommended pump capacity rotation [l] 6–25
Recommended pump capacity opening/closing [l] 25–40
Closing force [kN] 16
Torque [Nm] 1000
Number of teeth 3
